Hisense K360

Hisense K360 is made in the standard form factor and like most 32-inch TVs. TV mounted on a sturdy stand made of glossy plastic. Bottom left is the power indicator, and an infrared sensor to control with the remote control is placed on the opposite side. In the center of the lower edge of the manufacturer’s logo is located, and just below is a graceful display with white backlight.

Hisense K360

Hisense K360

The rear panel of the device is made of matte plastic practical. In the center of the rear panel are VESA Mounting 100? 100 mm in which the TV is easily mounted on the wall. There, on the rear panel, the control panel is available with the possibility of quick access to the settings, switch channels and adjust the volume. At the bottom of the case there are two dynamics at 7 watts each and a power button.

Ports and connectors are located on the left side edge. There are two ports USB 2.0, three HDMI interface, VGA port, two blocks of composite connectors, one block component interface, 3.5mm headphone jack, as well as connectors for coaxial cable antenna. Power supply and power cord built into the TV.

Hisense K360 is equipped with LED-backlit display and a 32-inch display with anti-reflective coating. Matrix used different natural colors and a wide viewing angle, which is 170 °. The display resolution is 1366 768 pixels, the aspect ratio is 16: 9, the maximum brightness reaches 350 cd / m2, and the display refresh rate is at 60 Hz.

Manage TV is easy: Hisense engineers have developed a friendly user interface that even a child will cope.

Hisense K360 supports video, photos and music from a USB-drive. We note in particular the regular remote control: it is made of matte plastic, it fits comfortably in the hand, and all the keys are comfortable and thoughtfully.
